Industrial Misting Fan - 30 Inch OSC - Misting pump

https://www.mistcooling.com/web/image/product.template/231/image_1920?unique=d554a20
MC23100

Industrial Misting Fan with 250 PSI Misting Pump:

  • 250 PSI Misting Pump
  • 30 Inch Weather Proof Misting Fan
  • 4 Nozzle Stainless Steel Misting Fan Ring

Industrial Misting Fan Components:

  • 1 - 250 PSI Misting Pump
  • 6 - Misting Nozzles
  • 1 - 30 Inch Outdoor, Wall Mount, Oscillating Fan
  • 1 - 6 Nozzles Misting Fan Ring Stainless Steel
  • 1 - 25 Ft Mist Tubing Roll
  • 1 - Feed Line

Misting Pump Specifications:

  • Maximum Inlet Pressure: 100 PSI
  • Minimum Inlet Pressure: Self-priming.
  • Maximum Outlet Pressure: 250 PSI (depends on line length and numbers of nozzles)
  • Maximum Flow: 0.9 GPM
  • Full load amps. 110V AC: 0.7 Amps12V DC: 4.0 Amps
  • Voltage: 110V-220V AC/ 12V DC (Refer manufacturing label on the pump)
  • Noise Level: 40 DB.
  • Maximum Fluid Temperature: For Room Temperature / Cold Water applications only

30 Inch Outdoor Fan Features:

  • Size: 30”
  • Color: White
  • RPM: 1115, AMPS: 2.65, CFM:10400
  • 3-speed Pull chain
  • Stainless Steel hardware with Durable
  • Corrosion-resistant finish
  • Motor with thermal Overlade protection industrial Grade aluminum blade
  • 10 Ft Heavy Duty cord with cord wrap
  • Quiet operation
  • For indoor/ Outdoor Use
  • Osha Approved Grill

Stainless Steel Fan Mist Ring Features:

  • Made with Industrial Grade 3/8'' Rigid Stainless Steel 316
  • Compatible with all High and Mid Pressure Mist Pumps
  • Pre-threaded nozzle slots for 10/24 Thread
  • Rated for up to 2000PSI
  • Attaches to any wall mount, floor, or pedestal fan
  • Includes Push-lock Inlet Fitting
  • Lifetime Warranty

1,099.99 1099.99 USD 1,099.99

1,099.99

Not Available For Sale

  • Number Of 30 Inch Fans

This combination does not exist.

Number Of 30 Inch Fans 1 Fan, 2 Fans, 3 Fans, 4 Fans, 5 Fans

15-Gallon Water Tank Lasts Up To 7 Hours of Intermittent Run Time and Is Easily Refillable.

Documents



Yes these are considered wall mount fans. Bracket can also be mounted on the ceiling with fan slightly tilted down

Fans should be placed 20-25 Feet apart

Is this battery powered and is the battery rechargeable?

No this is not battery powered. The fan must be plugged into a 110v outlet

This fan has a pull chain power and speed option. You can always add additional pull chain to desired length.
