Part Number:  MC32100

  • Ultra-Fine Brass Nozzles with Stainless-Steel orifices
  • Mid-Pressure 200 PSI or High-Pressure 1500 PSI outdoor-rated Pumps
  • 15-Gallon Water Tank
  • Two 24” high-velocity, outdoor-rated Industrial Cool Misting Fans
  • Stainless-Steel ring with 4, 6, or 8 Pre-threaded 10/24” Nozzle Slots
  • Ultra-Fine Brass Nozzles with Stainless-Steel orifices
  • Rolling Cart with pneumatic wheels
  • Can be powered by portable generator




1500 PSI Pump Specifications

  • Maximum Pump Speed (0.15/ 0.30 GPM): 1800 RPM
  • Maximum Inlet Pressure: 100 PSI
  • Minimum Inlet Pressure: (Based on setting on Pressure switch) or Flooded if the Pressure switch is bypassed
  • Maximum Outlet Pressure: 1500 PSI
  • Maximum Flow: 0.15, 0.30 GPM (Refer to manufacturing label on pump)
  • Full load amps. (0.15/ 0.30 GPM): 1.38 Amps. /2.15 Amps
  • Voltage: 110V/ 220V AC (Refer manufacturing label on the pump)
  • Noise Level: 75db
  • Maximum Fluid Temperature: For Room Temperature / Cold Water applications only

200 PSI Pump Specifications

  • Maximum Inlet Pressure: 100 PSI
  • Minimum Inlet Pressure: Self-priming (Capable of lifting water from 6 feet below.)
  • Maximum Outlet Pressure: 200 PSI (depends on line length and numbers of nozzles)
  • Maximum Flow: 0.5 GPM
  • Full load amps. (110V~220V AC/ 12V DC): Refer manufacturing label on the pump
  • Voltage: 110V-220V AC/ 12V DC (Refer manufacturing label on the pump)
  • Noise Level: appx. 35db
  • Maximum Fluid Temperature: For Room Temperature / Cold Water applications only



Stainless Steel Misting Fan Ring Specifications

  • Made with Industrial Grade 3/8'' Rigid Stainless Steel 316
  • Compatible with all High and Mid Pressure Mist Pumps
  • Pre-threaded nozzle slots for 10/24 Thread
  • Rated for up to 2000 PSI
  • Attaches to any wall mount, floor, or pedestal fan
  • Includes Push-lock Inlet Fitting
  • Nozzles & Fan Sold Separately
  • Lifetime Warranty

24-Inch Fan Features

  • Size: 24”
  • Color: Black or White
  • RPM: 1110, AMPS: 2.65, CFM:9100
  • Voltage: 110V
  • 3-speed Pull chain
  • Stainless Steel hardware with Durable Corrosion-resistant finish
  • Motor with thermal overload protection industrial
  • Grade aluminum blade
  • 10ft Heavy Duty cord with cord wrap
  • Quiet operation
  • For Indoor/ Outdoor Use
  • Osha Approved Grill
