Misting Fan with 24 Inch Outdoor Fan with 1500 PSI Misting Pump - With Stainless Steel Fan Misting Ring MC24120
Key Features (Bullet Points):
✔ Powerful Cooling – Combines a 24-inch OSC outdoor fan with a 1500 PSI misting pump for maximum cooling efficiency.
✔ Oscillating Fan – Provides wide coverage with oscillating movement, cooling a larger area effectively.
✔ High-Pressure Misting – Delivers a fine mist at 1500 PSI, creating a refreshing, cool breeze for outdoor spaces.
✔ Ideal for Outdoor Use – Perfect for patios, restaurants, outdoor events, and industrial spaces.
✔ Energy Efficient – Designed to provide maximum cooling with minimal energy consumption.
✔ Durable & Weather-Resistant – Built to withstand harsh outdoor conditions, ensuring long-lasting performance.
Description:
The Mist Fan with 24 Inch OSC Outdoor Fans and 1500 PSI Misting Pump is the ultimate cooling solution for outdoor spaces. This powerful system combines the high-pressure misting of the 1500 PSI pump with a 24-inch oscillating fan, creating a cool breeze that effectively lowers temperatures and enhances comfort. Ideal for patios, restaurants, event spaces, and industrial areas, this mist fan is built to withstand harsh outdoor conditions with its durable, weather-resistant design. Offering energy-efficient cooling, the Mist Fan ensures your outdoor environments stay comfortable and enjoyable while reducing energy costs.
You can run the line continuously from each fan using coupling tee's. The pump can be as far as 150 feet away from the first nozzle.
One year warranty on the pump and the fans. Please see our warranty page for more details.
Outdoor Misting Fan | Patio Misting Fan
Organizing an outdoor event? Worried that your guests may feel uncomfortable and some might even leave early because of the scorching heat? If yes, then consider investing in misting fans for the outdoors. For instant cooling, we recommend our 24” OSC mist fan kit.
This fan kit is easy to install and features a misting 1500psi pump with the ability to support up to 6 fans. It’s probably the best cooling system you’ll find in the market to keep venues like backyard, hotels, industrial plants, and even warehouses comfortable, employees cooling and relaxing without spending big. The 24” oscillating fan spreads the mist evenly to greater distances, resulting in much wider and comfortable cooling areas.
In comparison to other misting systems, this high-pressure kit is durable and whisper-quiet in operation. Besides that, you can place it on the floor or mount it on the wall according to your convenience.
You can now control the 1500 PSI misting pump with an add-on Smart phone controller ( Requires a strong WiFi signal at the pump)
1500 PSI Pump
- Maximum Outlet Pressure: 1500 PSI
- Maximum Pump Speed (0.50/ 1 / 2 GPM): 1750/ 1750/ 1750 RPM
- Maximum Inlet Pressure: 125 PSI
- Minimum Inlet Pressure: 40 PSI (Based on setting on Pressure switch) or Flooded if Pressure switch is bypassed
- Maximum Flow: 0.50, 1 & 2 GPM (Refer to manufacturing label on pump)
- Voltage: 110V/ 220V AC (Refer manufacturing label on the pump)
- Oil Type: AW-100
- Oil Capacity: 11.8oz
- Maximum Fluid Temperature: For Room Temperature / Cold Water applications only. (Please refer page 19 for full specs of the pump)
24 Inch Oscillating Fan
- Size: 24 inches
- Color: Black
- Mount Type: Wall mount
- CFM: 9100
- RPM: 1110
- Amps: 2.65
- Phase: 1
- HP: 1/4
Features:
- Extra-large high-velocity airflow with oscillation feature
- Durable and weather-resistant construction
- Suitable for outdoor use
- Adjustable tilt head for targeted airflow
- Oscillating function for wider coverage
- Power: Standard electric plug-in
Applications: Ideal for larger patios, decks, and commercial outdoor spaces
Installation: Easy wall mounting with provided hardware
15 Inch - 6 Nozzles
- Made with Industrial Grade 3/8'' Rigid Stainless Steel 316
- Compatible with all High and Mid Pressure Mist Pumps
- Pre-threaded nozzle slots for 10/24 Thread
- Rated for up to 2000PSI
- Attaches to any wall mount, floor, or pedestal fan
- Includes Push-lock Inlet Fitting
- Nozzles & Fan Sold Separately
- Lifetime Warranty
- 15'' Fan Mist Ring with 4 Nozzle's ports - Recommended for fans with 18''-20" Diameter
- 15'' Fan Mist Ring with 6 Nozzle's ports - Recommended for fans with 18-20'' Diameter
- 15'' Fan Mist Ring with 8 Nozzle's ports - Recommended for fans with 20-30'' Diameter
- 25'' Fan Mist Ring with 10 Nozzle's ports - Recommended for fans with 30-48'' Diameter
Specifications
| Number of 24 Inch Fans | 1 Fan, 2 Fans, 3 Fans, 4 Fans, 5 Fans, 6 Fans, 7 Fans (Requires Larger Pump), 8 Fans, 9 Fans, 10 Fans |
