Center Mist Fan Hub-PATENTED - With Magnetic option
Key Features (Bullet Points):
✔ Low Flow Design – Provides precise misting for efficient cooling and humidity control with minimal water usage.
✔ High-Quality Ceramic Construction – Durable, corrosion-resistant, and built to last for long-term performance.
✔ Ideal for Misting Systems – Perfect for patios, greenhouses, industrial humidification, and pest control applications.
✔ Red Color for Easy Identification – Unique color for easy distinction and organization in your misting setup.
✔ Precise Mist Output – Delivers an ultra-fine mist for even coverage and effective cooling or humidification.
Description:
The KBN Ceramic Nozzles – Red are designed for low-flow misting systems, providing efficient cooling and humidity control with minimal water consumption. These ceramic nozzles are durable and corrosion-resistant, ensuring long-lasting performance even in demanding conditions. Whether you're enhancing your patio, greenhouse, or industrial humidification system, these nozzles provide precise mist output, delivering a fine mist for even coverage and effective cooling. The red color makes these nozzles easy to identify and organize in your misting setup, ensuring seamless integration into your existing system.
KBN NOZZLE FEATURES
- Ultra-low flow rate hollow cone spray nozzle with the finest atomization among hydraulic nozzles.
- Minimal clogging with free passage diameter 1.3–2.6 times bigger than that of conventional nozzles.
- High-purity alumina ceramic tip provides stable performance with longer life even under high pressure conditions.
[STANDARD PRESSURE] 145.04 psi
[APPLICATIONS]
- Cooling: Poultry farms, outside cooling
- Humidifying: Air handling units, greenhouses
- Spraying: Alcohol, disinfectant
- Others: Dust suppression, irrigation for greenhouse
[DROPLET SIZE] : 35um - 65um ( Red ----> Purple)
[SPRAY ANGLE CODE] : 80
Structure
- One-piece plastic nozzle molded around a high-purity ceramic orifice.
- Thread is R1/4 (BSPT 1/4 male) or NPT 1/4 male.
- All models include a built-in strainer and check valve.
Material
- Nozzle orifice: ceramic
- Closer: polyester elastomer
- Nozzle body: PA
Weight
- 4 g
Max. operating pressure: 1000 psi
Nozzle Flow Rate - GPH - 1000 psi
Specifications
| Center Mist Fan Hub-PATENTED - Nozzle Type | Without Nozzle, KBN Red-Low Flow Nozzle, KBN Green-Mid Flow Nozzle, KBN Purple-High Flow Nozzle |
| Center Mist Fan Hub-PATENTED - Inlet Tube Size | 1/4 Inch OD, 3/8 Inch OD |
| Center Mist Fan Hub-PATENTED - Magnetic Option | Non Magnetic, Magnetic |
| Center Mist Fan Hub-PATENTED - Shut Off Valve | No Shut Off Valve, Shut Off Valve |
